A programmable oscillator is simply an oscillator in which the resonator frequency is post-processed to the desired output frequency utilizing an integer-mode or fractional-phase-locked loop (PLL). The resonator employed is either a bulk acoustic wave (BAW) quartz crystal resonator or a MEMS (Micro-Electro-Mechanical System) resonator. The oscillator output frequency and other operational functions are configured using the internal programmable memory of the integrated circuit. This circuit is comprised of an oscillator loop, a typical phase-locked loop (PLL) and associated functional blocks to facilitate various bias level and output logic configurations.
可編程振蕩器只是一個有源晶體振蕩器，其中使用整數模式或分數鎖相環 (PLL) 將諧振器頻率后處理到所需的輸出頻率。所采用的諧振器是體聲波 (BAW) 石英晶體諧振器或 MEMS（微機電系統）諧振器。振蕩器輸出頻率和其他操作功能使用集成電路的內部可編程存儲器進行配置。該電路由振蕩器環路、典型鎖相環路 (PLL) 和相關功能塊組成，以促進各種偏置電平和輸出邏輯配置。廣為人知的日蝕時鐘振蕩器編碼EB15K5D2H-32.768K

Utilizing a proprietary resonator design and exclusive programming methods, Ecliptek and associated Abracon brands of programmable oscillator series are configured to the specified frequency and functional configuration prior to shipment to the customer. Key features of this capability include fast delivery, greater availability of unique frequencies, various supply voltages and output logics, and industry-standard package sizes.
利用專有的諧振器設計和專有的編程方法，ECLIPTEK晶振和相關的Abracon品牌的可編程振蕩器系列在發貨給客戶之前配置為指定的頻率和功能配置。此功能的主要特點包括快速交付、更高的獨特頻率可用性、各種電源電壓和輸出邏輯以及行業標準封裝尺寸。廣為人知的日蝕時鐘振蕩器編碼EB15K5D2H-32.768K

EB15K2G2H-32.768K	CMOS	2.5Vdc	SMD 2.0mm x 2.5mm	±100ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K2H2H-32.768K	CMOS	2.5Vdc	SMD 2.0mm x 2.5mm	±50ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K2J2H-32.768K	CMOS	2.5Vdc	SMD 2.0mm x 2.5mm	±25ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K4C2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±100ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K4D2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±50ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K4E2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±25ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K4G2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±100ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K4H2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±50ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K4J2H-32.768K	CMOS	2.5Vdc	SMD 2.5mm x 3.2mm	±25ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K5C2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±100ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K5D2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±50ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K5E2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±25ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K5F2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±20ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K5G2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±100ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K5H2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±50ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K5J2H-32.768K	CMOS	2.5Vdc	SMD 3.2mm x 5.0mm	±25ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K7C2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±100ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K7D2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±50ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K7E2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±25ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K7F2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±20ppm	0°C to +70°C	50 ±5(%)	±5ppm
EB15K7G2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±100ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K7H2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±50ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB15K7J2H-32.768K	CMOS	2.5Vdc	SMD 5.0mm x 7.0mm	±25ppm	-40°C to +85°C	50 ±5(%)	±5ppm
EB16K2C2H-32.768K	CMOS	1.8Vdc	SMD 2.0mm x 2.5mm	±100ppm	0°C to +70°C	50 ±5(%)	±5ppm

Ecliptek’s programming capability offers a quick-turn delivery of low, medium and high-volume programmable oscillators, resulting in the shortening of the customer design cycle and the delivery of production lots. These solutions are ideally suited for industrial, consumer, data centers and telecommunications infrastructure architectures.
Ecliptek的編程能力可提供小、中、大容量可編程振蕩器和時鐘晶體振蕩器的快速交付，從而縮短客戶設計周期和生產批次的交付。這些解決方案非常適合工業、消費者、數據中心和電信基礎設施架構。
